SICK ENCODER DBS50E-S5EK00500

The SICK DBS50E‑S5EK00500 is a high‑precision incremental rotary encoder designed for industrial automation equipment. It offers 500 pulses per revolution, supports output interfaces such as TTL/RS422 and HTL/Push‑Pull, and operates from 7 V to 30 V DC. It features a solid shaft with an 8 mm diameter and a length of 15.5 mm. The encoder is housed in a flanged mounting body (Ø50 mm), rated IP65 for protection, and is capable of rotational speeds up to 8 000 rpm. Typical applications include motion control, machine positioning, and feedback systems in printing presses or other automation‑heavy machinery
